Thermal printing module
The new TS2000 series is a high-performance Thermal Printing Module for applications where reliability at an affordable price is a must.
Designed extremely small, compact and versatile to fit into limited spaces and all kind of easy integration structures.
General features
Speed
200mm/seg
Paper
58 mm
Temperature
-10ºc to 50ºc (non condensing)
Voltage
24Vdc
Speed
200mm/seg
Paper
58 mm
Temperature
-10º to 50º (non condensing)
Voltage
24Vdc
Technical specifications
Model
TS2000-58
Printing method
Thermal line dot system
Printer engine
Seiko CAPD247
Data Interface
RS232C & USB
Dot composition/line
432
Resolution (dpi)
203
Printing speed (mm/s)
200 max.
Paper width (mm)
58
Out of paper detection
Photo interrupter
Platen position detection
Mechanical switch
Auto cutter home detection
Photo interrupter
Operating voltage (VDC)
24
Operating ambient temperature (ºC)
-10 to 50 (non condensing)
Reliability (1) *Minimum pulse activation
100.000.000
*100Km
*100Km
Paper cut type
Full or partial cut
Autocutter lifetime
1.000.000 cuts or more
Dimensions WxDxH (mm) (2)
87 x 64 x 40
Weight (g) (2)
320
Model
TS2000-80
Printing method
Thermal line dot system
Printer engine
Seiko CAPD347
Data Interface
RS232C & USB
Dot composition/line
576
Resolution (dpi)
203
Printing speed (mm/s)
200 max.
Paper width (mm)
80
Out of paper detection
Photo interrupter
Platen position detection
Mechanical switch
Auto cutter home detection
Photo interrupter
Operating voltage (VDC)
24
Operating ambient temperature (ºC)
-10 to 50 (non condensing)
Reliability (1) *Minimum pulse activation
mínimo 100.000.000
*Minimum abrasion resistance 100Km
*Minimum abrasion resistance 100Km
Paper cut type
Full or partial cut
Autocutter lifetime
1.000.000 cuts or more
Dimensions WxDxH (mm) (2)
109 x 64 x 40
Weight (g) (2)
420
Bus ticketing
Weighing scales printers
Applications
Accessories
Code
Description
FAPOS-1/4
Power supply (match with 8016401 or 8016402)
8016401
Power supply cable
8016402
Power supply cable + DB9 serial cable
USB-3
Standard type-B USB cable
Order information
TS2000 X–Y
x=58mm paper width
x=80 80mm paper width
x=80 80mm paper width
y=nil: Standard type
y= XX: Custom-made type (only under agreement)
y= XX: Custom-made type (only under agreement)
